Specification
Value
Maximum Standby Rating
500 ekW @0.8pf
Fuel Type
Natural Gas
Emissions/Fuel Strategy
U.S. EPA Certified for Emergency Only Stationary Genset
Frequency
60 Hz
RPM
1800 rpm
Specification
Value
Engine Model
G3412
Displacement
1649 in³
Aspiration
NA
Bore
5.4 in
Stroke
6 in
Specification
Value
Length
165 in
Width
85.25 in
Height
86 in
Dry Weight - Genset
14700 lb
- Robust high speed block design provides prolonged life and lower owning operationg costs
- Designed for maximum performance on low pressure pipeline natural gas
- Simple open chamber combustion system for reliability and fuel flexibility
- Leading edge technology in ignition system and air/fuel ratio control for lower emission and engine efficiency
- One electronic control module handles all engine functions: ignition, governing, air/fuel ratio control and engine protection
- EPA Certified from the factoryfor use in Emergency applications
- User-friendly interface and navigation
- Scalable system to meet a wide range of installation requirement
- Expansion modules and site-specific programming for specific customer requirements
- Designed to operate in standard ambient temperatures up to 43°C (110°F)Contact your Cat Dealer for specific ambient and altitude capabilities
- Designed to match performance and output characteristics of Caterpillar gas engines
- Industry leading mechanical and electrical design
- High efficiency
- Wide range of bolt-on system expansion attachments
- Factory designed and tested
- Flexible packaging options for easy and cost effective installation
- Field proven in a wide range of applications worldwide
- Fully prototype tested
- Certified torsional vibration analysis available
- Cat dealers have over 1,800 dealer branch stores operating in 200 countries
- Your local Cat dealer provides extensive post-sale support, including maintenance and repair agreements
