M322D2
The M322D2 provides fast cycle times, great lift capacity and high bucket and stick forces. The new engine offers great power and reliability, while optimizing your fuel consumption. This combination maximizes your productivity in any job to maximize your profits.
Engine Model
Cat C7.1
Net Power
164 HP
Bore
4.13 in
Specification
Value
Engine Model
Cat C7.1
Net Power
164 HP
Bore
4.13 in
Stroke
5.31 in
Displacement
427.8 in³
Maximum Torque - 1,400 rpm
640.2 lb/ft
Ratings
2000 r/min
Power (Maximum) - ISO 14396 at 2,000 rpm
173 HP
Engine Gross Power (Maximum) - ISO 14396
173 HP
Power (Maximum) - ISO 9249 at 1,700 rpm
164 HP
Emission Standards
China Stage III Nonroad, U.S. EPA Tier 3/EU Stage IIIA equivalent emission standards
Number of Cylinders
6
Net Power - Rated - ISO 9249/SAE J1349
164 HP
Net Power - Rated - 80/1269/EEC
164 HP
Engine Gross Power (Maximum) - ISO 14396 - Metric
128.8 kW/175 hp (PS)
Net Power - Maximum - ISO 9249/SAE J1349
164 HP
Net Power (Rated) - ISO 9249/SAE J1349 - Metric
122 kW/166 hp (PS)
Bio Diesel up to B20
Meets EN 14214 or ASTM D6751 with EN590 or ASTM D975 standard mineral diesel fuels
Cat Bio HYDO™ Advanced
Readily biodegradable, EU Flower eco-label certified
Net Power - Maximum - 80/1269/EEC
164 HP
Engine Emissions
China Stage III Nonroad, and Tier 3/Stage IIIA equivalent
Net Power (Maximum) - ISO 9249/SAE J1349 (metric)
122 kW/166 hp (PS)
Specification
Value
Weight - VA Boom - Rear Dozer Only
43321 lb
Weight - VA Boom - Front and Rear Outriggers
46518 lb
Weight - One-Piece Boom - Rear Dozer Only
41888 lb
Operating Weight - With Attachment
20 500 kg-22 500 kg (45,195 lb-49,604 lb)
Operating Weight
20 500-22 500 kg (45,195-49,604 lb)
Weight - VA Boom - Rear Dozer, Front Outriggers
45966 lb
Weight - Counterweight - Standard
8598 lb
Weight - Counterweight - Optional (2)
11905 lb
Weight - Counterweight - Optional (1)
9700 lb
Weight - One-Piece Boom - Front and Rear Outriggers
45085 lb
Weight - Sticks - Long (2900 mm)
1720 lb
Weight - Sticks - Medium (2500 mm)
1543 lb
Weight - One-Piece Boom - Rear Dozer, Front Outriggers
44533 lb
Weight - Sticks - Short (2200 mm)
1433 lb
Specification
Value
Swing Speed
9.0 r/min
Swing Torque
41303 lb/ft
Specification
Value
Maximum Pressure - Implement Circuit - Travel Circuit
5076 psi
Maximum Flow - Auxiliary Circuit - Medium Pressure
13.2 gal/min
Maximum Pressure - Implement Circuit - Heavy Lift
5439 psi
Maximum Pressure - Swing Mechanism
4931 psi
Maximum Pressure - Implement Circuit - Normal
5076 psi
Maximum Flow - Swing Mechanism
29.6 gal/min
System
92.5 gal (US)
Maximum Pressure - Auxiliary Circuit - High Pressure
5076 psi
Maximum Flow - Auxiliary Circuit - High Pressure
66.0 gal/min
Maximum Flow - Implement/Travel Circuit
92.5 gal/min
Tank Capacity
58.1 gal (US)
Maximum Pressure - Auxiliary Circuit - Medium Pressure
2683 psi
Specification
Value
Drawbar Pull
25269 lbf
Creeper Speed - 1st Gear
1.9 mile/h
Forward/Reverse - 1st Gear
4.3 mile/h
Maximum Gradeability (21 000 kg)
60.2%
Forward/Reverse - 2nd Gear
15.5 mile/h
Creeper Speed - 2nd Gear
7.5 mile/h
Specification
Value
Engine Crankcase
4.0 gal (US)
Final Drive
0.7 gal (US)
Powershift Transmission
0.7 gal (US)
Rear Axle - Housing (Differential)
3.7 gal (US)
Cooling System
9.8 gal (US)
Front Steering Axle - Differential
2.9 gal (US)
Fuel Tank - Total Capacity
101.7 gal (US)
Specification
Value
Standard
11.00-20 (dual pneumatic)
Optional
10.00-20 (dual solid rubber)
Specification
Value
Ground Clearance
15.0 in
Minimum Turning Radius - End of One-Piece Boom
366.1 in
Minimum Turning Radius - End of VA Boom
307.1 in
Minimum Turning Radius - Outside of Tire
267.7 in
Oscillation Axle Angle
±9°
Maximum Steering Angle
35°
Specification
Value
Bucket Capacities
0.44 m³-1.57 m³ (0.58 yd3-2.05 yd3)
Specification
Value
Maximum Reach - Ground Level
33.9 ft
Maximum Digging Depth
21.9 ft
Specification
Value
Maximum Travel Speed
15.5 mile/h
Specification
Value
Operator Sound - 2000/14/EC
74 dB(A)
Exterior Sound - 2000/14/EC
103 dB(A)
Specification
Value
Vibration Levels - Maximum Whole Body - ISO/TR 25398:2006
<0.5 m/s² (<1.6 ft/s2)
Vibration Levels - Seat Transmissibility Factor - ISO 7096:2000 - Spectral Class EM6
<0.7
Vibration Levels - Maximum Hand/Arm - ISO 5349:2001
<2.5 m/s² (<8.2 ft/s2)
Note
*Not available in all markets. Available only for Africa, Middle East and Eurasia. Please contact your Cat dealer for details.
Cab/ROPS*
ROPS (Rollover Protective Structure) offered by Caterpillar meets ROPS criteria ISO 12117-2:2008
Cab/Sound Levels
Meets appropriate standards as listed in “Sound Performance”
Cab - FOPS
Cab with FOPS (Falling Object Protective Structure) meets FOPS criteria ISO 10262:1998 and SAE J1356:2008
Specification
Value
Blade Width
108.3 in
Specification
Value
Maximum Raising Height Above Ground
19.3 in
Blade Type
Radial
Maximum Lowering Depth from Ground
5.1 in
Blade Roll - Over Height
22.7 in
Blade Total Height
24.0 in
- Cat C7.1 engine meets EU Stage IIIA, U.S. EPA Tier 3equivalent emission standards and meets China Nonroad III emission standards.
- Engine fuel system designed to manage world-wide fuel quality and provide outstanding low fuel consumption during both working and traveling applications.
- One-Touch Low Idle Control. The Automatic Engine Speed Control reduces engine speed if no operation is performed, reducing fuel consumption and sound levels.
- Constant Power Strategy, providing a quick response to changing loads, while delivering the same amount of power.
- Choice of various booms and sticks provides the right balance of reach and digging forces for all applications.
- Dedicated Swing Pump allows faster and smoother combined movements when using the implements while swinging.
- Multiple configurations meet all your applications needs, with a choice of booms, sticks, blade and/or stabilizer undercarriages.
- Highly mobile, the M322D2 can travel up to 25 km/h.
- Standard one-way high pressure hydraulics allow customers to install attachments like hammers without adding other lines.
- Ten hydraulic pump flow and pressure settings can be preset within the monitor allowing quicker and easier attachment changes.
- A lifting eye into the bucket linkage, the heavy lift mode and the overload warning signal allow operators to safely lift heavy loads.
- Wide range of Cat attachments to handle any job at hand.
- ROPS cab structure and Operator Protective Structure (top and front guards) are available.
- Ergonomically designed cab with controls kept to a minimum, conveniently located and easy to operate.
- The optional air-suspension seat, with automatic weight adjustment and heated cushions enhance comfort and productivity.
- Safety is enhanced by the all-round visibility provided by large glass areas and skylight and the standard rear-mounted camera image displayed on the full color monitor.
- Low sound levels, as a result of the variable fan speed and remote cooling system enabling the machine to be used in noise sensitive areas like urban areas.
- 500 hours fuel filter replacement (reduced to 250 hours if fuel quality is sub-standard) allows reduced maintenance cost.
- All daily maintenance points are accessible from ground level.
- Clean design, with colored and numbered electrical wires, protected by thick braiding for ease of service.
- Greasing points are centralized and kept to a minimum.
- Cat XT™-6 ES hoses are resistant and durable, which reduce the risk of leaks that can reduce the performance of the machine.
- Rigidity and long life with effective transmission protection and heavy duty axle.
- Standard heavy duty batteries for improved cold start capability
- Cat technology solutions increase production and minimize operating costs. Link technologies wirelessly connect you to your job site, providing machine location, hours, fuel usage, idle timeand event codes.
General Duty Bucket 1300 mm (51 in): 462-9436
General Duty Bucket 1400 mm (55 in): 550-9666
General Duty - Leveling Edge Bucket 1400 mm (55 in): 468-3206
General Duty Bucket 1400 mm (55 in): 462-9437
General Duty - Leveling Edge Bucket 1000 mm (39 in): 462-8168
General Duty - Leveling Edge Bucket 1500 mm (60 in): 468-1691
General Duty - Leveling Edge Bucket 1500 mm (59 in): 462-9438
General Duty Bucket 1200 mm (48 in): 550-9635
General Duty Bucket 900 mm (35 in): 550-9633
General Duty Bucket 1050 mm (42 in): 550-9634
General Duty Bucket 750 mm (30 in): 550-9668
General Duty Bucket 900 mm (36 in): 550-9669
General Duty - Leveling Edge Bucket 1200 mm (48 in): 455-0750
General Duty - Leveling Edge Bucket 1200 mm (47 in): 455-0749
General Duty Bucket 1200 mm (47 in): 550-9765
General Duty Bucket 750 mm (30 in): 550-9763
General Duty Bucket 1050 mm (41 in): 550-9764
General Duty Bucket 1350 mm (54 in): 550-9766
General Duty Bucket 600 mm (24 in): 550-9664
General Duty - Leveling Edge Bucket 650 mm (25 in): 485-7488
General Duty - Leveling Edge Bucket 800 mm (31 in): 485-7596
General Duty Bucket 1200 mm (48 in): 550-9631
General Duty Bucket 1200 mm (48 in): 462-9435
General Duty Bucket 1300 mm (51 in): 550-9665
General Duty Bucket 1300 mm (51 in): 550-9632
General Duty Bucket 1500 mm (60 in): 550-9762
General Duty - Leveling Edge Bucket 1600 mm (63 in): 462-9439
Heavy Duty Bucket 900 mm (36 in): 573-5002
Heavy Duty Bucket 1300 mm (852 in): 550-9544
Heavy Duty Bucket 1200 mm (48 in): 550-9680
Heavy Duty Bucket 1200 mm (48 in): 550-9659
Heavy Duty Bucket 600 mm (24 in): 550-9658
Heavy Duty Bucket 1650 mm (66 in): 541-1779
Heavy Duty Bucket 1350 mm (54 in): 541-1778
Heavy Duty Bucket 1050 mm (42 in): 573-5003
Heavy Duty Bucket 1200 mm (48 in): 573-5009
Heavy Duty Bucket 600 mm (24 in): 550-9677
Heavy Duty Bucket 1200 mm (48 in): 550-9656
Heavy Duty Bucket 1300 mm (51 in): 550-9678
Heavy Duty Bucket 1300 mm (51 in): 550-9657
Severe Duty Bucket 1050 mm (42 in): 541-1780
Severe Duty Bucket 1200 mm (47 in): 573-4983
Severe Duty Bucket 1350 mm (54 in): 541-1781
Ditch Cleaning Bucket 2100 mm (83 in): 441-6090
Ditch Cleaning Bucket 2100 mm (83 in): 441-6087
Ditch Cleaning Bucket 2100 mm (83 in): 441-6093
Ditch Cleaning Bucket 1800 mm (72 in): 441-6091
Ditch Cleaning Bucket 1800 mm (72 in): 461-4189
Ditch Cleaning Bucket 1800 mm (72 in): 461-4191
Ditch Cleaning Bucket 2200 mm (87 in): 461-4194
Ditch Cleaning Bucket 2100 mm (83 in): 461-4192
Ditch Cleaning Bucket 1800 mm (72 in): 441-6082
Ditch Cleaning Bucket 2200 mm (87 in): 441-6079
Ditch Cleaning Bucket 1800 mm (72 in): 461-4183
Ditch Cleaning Bucket 2000 mm (78 in): 441-6078
Grading Bucket 1800 mm (70 in): 514-7844
Grading Bucket 1800 mm (70 in): 514-7843
Profile Bucket 300 mm (12 in): 287-5363
Profile Bucket 300 mm (12 in): 326-7404
Profile Bucket 400 mm (16 in): 326-7405
Profile Bucket 500 mm (20 in): 223-1383
Profile Bucket 500 mm (20 in): 214-1022
Profile Bucket 500 mm (20 in): 326-7406
Trenching Bucket 600 mm (23 in): 514-7846
Trenching Bucket 660 mm (26 in): 514-7845
Utility Duty Bucket 1200 mm (48 in): 186-6740
Utility Duty Bucket 1300 mm (51 in): 226-2146
Utility Duty Bucket 1400 mm (55 in): 226-1674
Utility Duty Bucket 1500 mm (60 in): 226-2141
Utility Duty Bucket 1700 mm (67 in): 226-2142
Ditch Cleaning Tilt Bucket 2000 mm (79 in): 511-5339
Ditch Cleaning Tilt Bucket 2000 mm (79 in): 511-5340
G318 Demolition & Sorting Grapple: 587-8965
G318 WH Demolition & Sorting Grapple: 587-8970
G318 Demolition & Sorting Grapple: 587-8966
G318 WH Demolition & Sorting Grapple: 587-8975
CTV15-1000 Clamshell Grapple
CTV15-1200 Clamshell Grapple
CTV15-1500 Clamshell Grapple
GSH420 4-Tine, 500-Liter Orange Peel Grapple
GSH420 4-Tine, 600-Liter Orange Peel Grapple
GSH420 4-Tine, 750-Liter Orange Peel Grapple
GSH425 4-Tine, 1150-Liter Orange Peel Grapple
GSH520 5-Tine, 500-Liter Orange Peel Grapple
GSH520 5-Tine, 600-Liter Orange Peel Grapple
GSH425 4-Tine, 950-Liter Orange Peel Grapple
GSH520 5-Tine, 750-Liter Orange Peel Grapple
GSH525 5-Tine, 1150-Liter Orange Peel Grapple
GSH525 5-Tine, 750-Liter Orange Peel Grapple
GSH525 5-Tine, 950-Liter Orange Peel Grapple
GSV520 GC 5-Tine, 400-Liter Orange Peel Grapple
GSV520 GC 5-Tine, 500-Liter Orange Peel Grapple
GSV520 GC 5-Tine, 600-Liter Orange Peel Grapple
GSV520 GC 5-Tine, 750-Liter Orange Peel Grapple
GSV520 5-Tine, 400-Liter Orange Peel Grapple
GSV520 5-Tine, 500-Liter Orange Peel Grapple
GSV520 5-Tine, 600-Liter Orange Peel Grapple
GSV520 5-Tine, 750-Liter Orange Peel Grapple
GSV525 5-Tine, 1150-Liter Orange Peel Grapple
GSV525 5-Tine, 600-Liter Orange Peel Grapple
GSV525 5-Tine, 750-Liter Orange Peel Grapple
GSV525 5-Tine, 950-Liter Orange Peel Grapple
H120 GC
H120 GC S
H115 S
H120 S
H130 S
MP318 Universal Jaw
MP318 Pulverizer Jaw
MP318 Shear Jaw
Cat® Detect with Smart Camera
Cat® Detect with Surround Cameras
Cat Product Link
Cat Inspect
VisionLink®
VisionLink® Productivity
G318 WH Demolition & Sorting Grapple: 587-8976
G318 Demolition & Sorting Grapple: 595-1393
G317 GC Demolition & Sorting Grapple: 587-8720
G317 GC Demolition & Sorting Grapple: 587-8721
GSH425 4-Tine, 750-Liter Orange Peel Grapple
MP318 Demolition Jaw
MP318 Concrete Cutter Jaw
Cat 2D E-fence for Excavators
Cat Payload for Excavators
